CARGOMAX™ Aluminum

Authorized CARGOMAX™ Aluminum Dealer

Model specifications

Model	GVWR LBS/KGS	Cargo Load LBS/KGS	NET WT LBS/KGS	STANDARD TIRES	UPGRADE TIRE	MAX TONGUE WT LBS/KGS	TONGUE JACK	TAILGATE RAMP	INSIDE LENGTH	INSIDE WIDTH	SIDEWALL	OUTSIDE WIDTH (INCL FENDERS)	OUTSIDE LENGTH
XRT 8-57 Single Axle-No Brakes	2140/969	1800/815	290/132	5.30X12″ -C	ST145-R12 Alum. Radial	125/56	STD	Single	96″	57″	12″-13.5″	70″	150″
2014-2020 – XRT 9.5-73 Single Axle-No Brakes (2014-20 Models)	2800/1270	2200/998	480/218	205-75R14 Steel Radial	205-75R14 Alum. Radial	220/100	STD	Bi-Fold	114″	73″	11.5″-16″	93.5″	167″
2021 – XRT 9.5-73 Single Axle-No Brakes (2021 Model)	2990/1356	2380/1080	520/236	205-75R14 Steel Radial	205-75R14 Alum. Radial	300/136	STD	Bi-Fold	114″	73″	11.5″-16″	93.5″	167″
2014-2020 – XRT 11-73 Single Axle-No Brakes (2014-20 Models)	2800/1270	2200/998	540/231	205-75R14 Steel Radial	205-75R14 Alum. Radial	220/100	STD	Bi-Fold	132″	73″	11.5″-16″	93.5″	184″
2021 – XRT 11-73 Single Axle-No Brakes (2021 Model)	2990/1356	2380/1080	580/263	205-75R14 Steel Radial	205-75R14 Alum. Radial	300/136	STD	Bi-Fold	132″	73″	11.5″-16″	93.5″	184″
2014-2020 – XRT 13-73 Single Axle-No Brakes (2014-20 Models)	2800/1270	2200/998	570/258	205-75R14 Steel Radial	205-75R14 Alum. Radial	220/100	STD	Bi-Fold	156″	73″	11.5″-16″	93.5″	212″
2021 – XRT 13-73 Single Axle-No Brakes (2021 Model)	2990/1356	2380/1080	610/277	205-75R14 Steel Radial	205-75R14 Alum. Radial	300/136	STD	Bi-Fold	156″	73″	11.5″-16″	93.5″	212″
XRT 13-73 T Tandem Axle-W/Brakes	2990/1356	2200/998	780/354	205-75R14 Steel Radial	205-75R14 Alum. Radial	440/200	STD	Bi-Fold	156″	73″	11.5″-16″	93.5″	212″
XRT 13-73 T Tandem Axle W/Brakes	4400/2000	3470/1577	930/422	205-75R14 Steel Radial	205-75R14 Alum. Radial	440/200	STD	Bi-Fold	156″	73″	11.5″-16″	93.5″	212″

Cargomax™ Videos

Advanced design combines an aluminum frame with a highly impact-resistant polymer Ultra Body™. We tried to find out how virtually indestructible the Ultra-Body™ really is.
