Standard Features

RC Trailers

Hitch

  • 2’ Coupler – Single Axle Models
  • 2-5/16” Coupler – Tandem Axle Models
  • 2,000 lb. Top Wind Jack w/ Sand Pad
  • Safety Chains

Axle
5’, 6’, 7’ Wides

  • SA Models – 3,000 lb. Spring Idler Axle
  • SAE Models – 3,500 lb. Spring Brake Axle
  • TA2 Models – 3,500 lb. Spring Brake Axles

8.5’ Wides

  • TA2 Models – 3,500 lb. Spring Brake Axle
  • TA2 Models – 5,200 lb. Spring Brake Axle

Tires and Rims

  • ST205/75D115 Bias w/ White Wheels on 3,000 lb. and 3,500 lb. Axles
  • ST225/75R115 Radial w/ White Wheels on 5,200 lb. Axles

Frame

  • 24” On Center Floor, Roof, and Walls
    Note: 16” On-Center Floor with TA3 Axles and Up 18” Wedge Nose Undercoated Frame

Side Door – All Doors with NO Step
5’, 6’, 7’ Wides

  • 24” Door w/ Barlock on 8’ Long Models
  • 32” Door w/ Barlock on other 5’ & 6’ Wide Models
  • 36” Door w/ Barlock on 7’ Wide Models
8.5’ Wides
  • 36” Door w/ Barlock on 16’ and Shorter Models
  • 48” Door w/ Barlock on 18’ and Shorter Models

*Light Duty Ramp Door has a 1,000 lb. capacity

Interior
  • 3/4″ Engineered Wood Flooring
  • 3/8″ Plywood Walls Trimmed with Lauan
Exterior
  • Flor-Thru Sidewall Vents
  • .030 Exterior Metal
  • Inverted ATP Stoneguard
  • Galvanized Steel Roof
  • Mill Finish Rear Corners and header
  • ATP Fenders
  • 1-1/2″ Lower Trim
  • 3” Top Rail

Electrical

  • (1) 12-Volt LED Dome Light
  • 4-Way Plug on idler Axles
  • 7-Way Plug on Electric Brake Axles
  • Breakaway Box, Battery, & Switch
  • LED Strip Tail Light/Brake Lights, Surf Mounted
  • LED Surface Mounted Clearance Lights
5,200 lb. Axle Upgrades (TA3)
Includes: Upgraded Floor, Crossmembers to 16″ On-Center and 3rd member Tongue
Note: Can Only Be Used on Models That Don’t Already Include TA# Published Prices
5,200 lb. Axle Upgrades (TA3) – In Place of Tandem 3,500 lb. Axles
Add Triple 5,200 lb. Axle (TR52)
6,000 lb. Axle Upgrades (TA4)
6,000 lb. Tandem Axles – In Place of 5,200 lb. Tandem Axles
6,000 lb. Triple Axles – In Place of 5,200 lb. Tandem Axles
6,000 lb. Triple Axles – In Place of 5,200 lb. Triple Axles
6,000 lb. Tandem Axles – In Place of Triple 5,200 lb. Axles
7,000 lb. Axle Upgrades (TA5)
7,000 lb. Tandem Axles – In Place of 5,200 lb. Tandem Axles
7,000 lb. Tandem Axles – In Place of 5,200 lb. Triple Axles
7,000 lb. Triple Axles – In Place of 5,200 lb. Tandem Axles
7,000 lb. Triple Axles – In Place of 5,200 lb. Triple Axles
8,000 lb. Axle Upgrades (TA6)
8,000 lb. Tandem Axles – In Place of 5,200 lb. Tandem Axles
8,000 lb. Tandem Axles – In Place of 5,200 lb. Triple Axles
8,000 lb. Triple Axles – In Place of 5,200 lb. Tandem Axles
8,000 lb. Triple Axles – In Place of 5,200 lb. Triple Axles
Other Axle Options
3,500 lb. Electric Brake – In Place of 3,000 lb. Idler Axle
10,000 lb. Axles
All Ride Axles



Standard Axle, Wheels, and Tires



Axle Standard Tires Wheel
3,000 lb. Spring ST205/75/D15C White Steel
3,500 lb. Spring ST205/75/D15C White Steel
5,200 lb. Spring ST225/75/R15D White Steel
3,000 lb. Torsion ST205/75/R15C White Steel
3,500 lb. Torsion ST205/75/R15C White Steel
5,200 lb. Torsion ST225/75/R15D White Steel
6,000 lb. Torsion/Spring 235/80/R16E White Steel
7,000 lb. Torsion/Spring 235/80/R16E White Steel
8,000 lb. Torsion 235/75/R17.5H Silver Steel



RWT 5’, 6’, 7’, & 8.5’ Spring Axle Flat Top 18” Cargo Trailer



Rear Door
Width Single Door Double Door Ramp Door
5′ X X *Light Duty
6′ X *Light Duty
7′ X *Light Duty
8.5′ X 3,000 lb.





Interior Heights
4′ Wides – 4′ 7′ Wides – 6′
5′ Wides – 5′-6″ 8.5′ Wides – 6’6″
6′ Wides – 6′





Model
4′ Wide – Single 2,000 lb. Axle
RWT 4 x 6 SA (A-Frame)
RWT 4 x 8 SA (A-Frame)
5′ Wide – Single 3,000 lb. Axle
RWT 5 x 8 SA
RWT 5 x 10 SA
RWT 5 x 12 SA
5′ Wide – Single 3,500 lb. Axles
RWT 5 x 8 SA
RWT 5 x 10 SA
RWT 5 x 12 SA
5′ Wide – Tandem 3,500 lb. Axles
RWT 5 x 10 SA
RWT 5 x 12 SA
6′ Wide – Single 3,000 lb. Axle
RWT 6 x 10 SA
RWT 6 x 12 SA
6′ Wide – Single 3,500 lb. Axle
RWT 6 x 8 SAE
RWT 6 x 10 SAE
RWT 6 x 12 SAE
RWT 6 x 14 SAE
6′ Wide – Tandem 3,500 lb. Axles
RWT 6 x 10 TA2
RWT 6 x 12 TA2
RWT 6 x 14 TA2
6′ Wide – Tandem 5,200 lb. Axles
RWT 6 x 8 TA3
RWT 6 x 10 TA3
RWT 6 x 12 TA3
RWT 6 x 14 TA3
7′ Wide – Single 3,000 lb. Axle
RWT 7 x 10 SA
RWT 7 x 12 SA
7′ Wide – Single 3,500 lb. Axle
RWT 7 x 10 SAE
RWT 7 x 12 SAE
7′ Wide – Tandem 3,500 lb. Axles
RWT 7 x 10 TA2
RWT 7 x 12 TA2
RWT 7 x 14 TA2
RWT 7 x 16 TA2
RWT 7 x 18 TA2
RWT 7 x 20 TA2
7′ Wide – Tandem 5,200 lb. Axles
RWT 7 x 14 TA3
RWT 7 x 16 TA3
RWT 7 x 18 TA3
RWT 7 x 20 TA3
8.5′ Wide – Tandem 3,500 lb. Axles
RWT 8.5 x 14 TA2
RWT 8.5 x 16 TA2
RWT 8.5 x 18 TA2
RWT 8.5 x 20 TA2
RWT 8.5 x 22 TA2
RWT 8.5 x 24 TA2
8.5′ Wide – Tandem 5,200 lb. Axles
RWT 8.5 x 14 TA3
RWT 8.5 x 16 TA3
RWT 8.5 x 18 TA3
RWT 8.5 x 20 TA3
RWT 8.5 x 22 TA3
RWT 8.5 x 24 TA3
RWT 8.5 x 26 TA3
RWT 8.5 x 28 TA3-Maximum Length!





Popular Options (RWT Models Only)
Item
16″ Wood Flap Added to Light Duty Ramp Door
Flush Lock Side Door Lock
(1) Piece Aluminum Roof
Light-Duty Stabilizer Jacks
Two-Tone Without Bright Stripe
Two-Tone With 4″ Bright Stripe
Radial Tires in Place of Bias-Ply Tires
Brown Lauan Ceiling
Add Insulation to Ceiling
ATP Flooring, White Vinyl Ceiling, Plywood Ceiling, Ceiling Insulation
Exterior Metal Upgrade
Note: For floor and ceiling calculations, add 2 feet to the call size of the trailer to allow for the length of the wedge: Example for a 7×10 trailer, use 12′ for the floor and ceiling calculations.
Packages
Car Hauler Package (RWT 8′ or 8.5′ Wides Only – Includes the following:
16″ On-Center Sidewalls
Beavertail (2′ Beavertail on 16′, 4′ Beavertail on 18′ and longer)
(4) Heavy-Duty D-Rings
Screwless Package
Screwless Exterior Metal
16″ On-Center Sidewalls
Flash Package
12″ ATP On Sides
Flush Lock
