Single Axle Tilt Bed Equipment

LOE-SINGLE-AXLE-TILT-BED-EQUIPMENT1-1920w

Standard Features

Single Axle Tilt Bed Equipment

  • NEW: A-Frame Toolbox
  • Tube Construction
  • All LED Lights
  • Torsion Axle (22.5 Degree Up)
  • Sealed Brake Connections
  • EverLink™ – High-Performance Wiring Harness
  • Pressure-Treated 2 x 6 Decking
  • Hydraulic Dampener
  • Easy-Lube Hubs
  • White Spoke Wheels
  • Radial Tires
  • 7K Dropleg Jack
  • Adjustable 2-5/16″ Coupler
  • Tube Full Wrap Tongue
  • HD Diamond Plate Knife Edge Tail
  • Stake Pockets and Rub Rail
  • (4) D-Ring
  • HD Reinforced Tread Plate Fenders
  • Rear Board Retainers
Specifications 5 x 10, 6K 6.5 x 12, 7.8K 6.5 x 12 + 4, 7.8K 6.5 x 12, 10K 6.5 x 12 + 4, 10K
GVWR 6000 7800 7800 9900 9900
GAWR 5200 7000 7000 8000 8000
Curb Weight 1360 1900 2100 2200 2400
Payload 4640 5900 5700 7700 7500
Frame 5 x 2 Tube
Cross Members C-Channel (16″ On-Center)
Tongue 5 x 2 Tube
Coupler Adjustable 2 5/16″
Jack 7K Dropleg, Set Back
Fenders HD Tread Plate
Axles Torsion Axle (22.5 Degree Up)
Tires 225/75R15 LRD 235/80R16 LRE 215/75R17.5 LRH
Wheels 15″, 6 on 5.5, Radial 16″, 8 on 6.5, Radial 17.5″, 8 on 6.5, Radial
Decking 2 x 6 Treated Pine
Lights All LED Lights
Electric Plug 7 Pole RV Molded Flat Blade
Finish Powder Coated High Gloss Black
Length (Overall/Bed) 189.5″ / 129.5″ 214.5″ / 154.5″ 264.5″ / 204.5″ 214.5″ / 154.5″ 264.5″ / 204.5″
Between Fenders 62″ 78″ 78″ 78″ 78″
Deck Height 17″ 19″ 19″ 21″ 21″
Coupler Height 8″ – 17″ 10″ – 19″ 10″ – 19″ 10″ – 19″ 10″ – 19″
Tilt Angle 12 Deg. 11 Deg. 11 Deg. 11 Deg. 11 Deg.

Want to talk more about our Single Axle Tilt Bed Equipment?

Contact us for trailer sales or repair in WNY.
