ATV Utility

LOE-atvangleiron1-1920w

Standard Features

ATV Utility

  • Fold Flat Ramp gate with handle
  • DOT Approved led sealed lighting
  • 2 x 6 Treated Deck
  • TREAD PLATE FENDERS
  • Powder Coat Finish
  • 15″ RADIAL TIRES (205/75/R15 LRC) 3.5K AXLE
  • EZ Lube Hubs
  • Gel-Filled Electrical Connectors
  • (2k zinc plated set-back jack)
  • Board Retainers Front and Back
  • 5′ Fabricated Steel Ramps (side storing
  • Bead Blasted, Iron Phosphate Washed
  • Wiring enclosed in tubular steel
  • Self retained gate pins
  • Tube uprights
  • 2×2 heavy tube top rail for structural rigidity
  • spare tire carrier
  • stake pockets
  • Spring -assisted Rear Ramp Gate
Specifications 6’x12′(3K) 7’x12′ (3K) 7’x14′ SA (3K) 7’x14′ TA (7K) 7’x16′ (7K)
GVWR (lbs.) 2990 2990 2990 7000 7000
GAWR (lbs./axle) 3500 3500 3500 3500 3500
Curb Weight (lbs.) 1320 1370 1450 1740 1910
Payload (lbs.) 1670 1620 1540 5260 5090
Length Overall (in.) 185″ 185″ 209″ 209″ 237″
Bed Length (in.) 144″ 144″ 168″ 168″ 192″
Bed Width (in.) 71.5″ 81.5″ 81.5″ 81.5″ 81.5″
Deck Height (in.) 18″ 18″ 18″ 18″ 18″
Coupler Height (in.) 16″ 16″ 16″ 16″ 16″
